| 記 号 |
ＰＴ1 |
ＰＴ2 |
Ａ1
(mm) |
Ａ2
(mm) |
二面幅
Ｂ(mm) |
Ｃ
(mm) |
ΦＤ(mm) |
(Ｌ1)
(mm) |
(Ｌ2)
(mm) |
| ＬＣＺ０１−０１Ｍ |
1/8PT |
1/8PT |
8 |
8.5 |
12 |
6 |
5 |
17 |
20 |
| ＬＣＺ０２−０２Ｍ |
1/4PT |
1/4PT |
12 |
12 |
16 |
8 |
6 |
23 |
28 |
| ＬＣＺ０３−０３Ｍ |
3/8PT |
3/8PT |
14 |
14 |
22 |
10 |
8 |
28 |
36 |
| ＬＣＺＭ０１−０１ |
1/8PT |
1/8PT |
9 |
9 |
12 |
7 |
5 |
23 |
20 |
| ＬＣＺＭ０２−０２ |
1/4PT |
1/4PT |
12 |
12 |
16 |
8.5 |
6 |
29 |
25 |
| ＬＣＺＭ０３−０３ |
3/8PT |
3/8PT |
14 |
14 |
22 |
11 |
8 |
36 |
32 |
|
|
|
|
|
|
|
 |
|
 |
|
|
